jjw-500156
The 500156 electric wheelchair is equipped with solid wheels with aluminum wheel hubs for stable performance.
Specifications
| Model Number | 500156 |
| Motor | Brush 250W × 2 pcs, EABS brake |
| Brake | EABS brake |
| Battery | DC24V 12AH lead acid battery 8.5KGS |
| Charger | Input: AC180-240V 50-60Hz; Output: DC24V |
| Charging Time | 6-8 hours |
| Controller | Brush controller |
| Frame Material | Carbon Steel |
| Size (Unfold) | 111 * 61 * 90 CM |
| Size (Folded) | 68 * 39 * 72 CM |
| Carton Size | 73 * 39 * 72.5 CM |
| Front Wheel | 8 inch PU wheel |
| Rear Wheel | 12 inch solid wheels with aluminum hub |
| Seat Width | 56 CM |
| Seat Height | 57 CM |
| Seat Depth | 42 CM |
| Backrest Height | 42 CM |
| Max Load | 150 KG |
| Gross Weight | 45.62 KG |
| Net Weight | 40.7 KG (with 20AH battery) |
Product Features
Solid Wheels with Aluminum Hubs
The 500156 electric wheelchair is equipped with solid wheels with aluminum wheel hubs for stable performance.
Motor
Brush 250w*2pcs (with EABS brake)
Battery
DC24V 12AH lead-acid battery (8.5KGS)
Charger
Input AC180-240V 50-60Hz; Output DC24V; Charging time: 6-8 hours
Controller
Brush controller
Frame Material
Carbon steel
Dimensions
Unfolded (111*61*90 CM) / Folded (68*39*72 CM) / Carton (73*39*72.5 CM)
Wheels
8-inch PU front wheel; 12-inch solid rear wheels (aluminum hub)
Seat & Backrest
Width 56CM / Height 57CM / Depth 42CM; Backrest height 42CM
Load & Weight
Max load 150KG; Gross weight 45.62kg; Net weight (with 20AH battery) 40.7kg
Product Details
