JJW-600111
The 60111 electric wheelchair is a basic aluminum model with manual folding (non-reclinable), offering 2 optional wheel and connector configurations for customization.
Specifications
| Model Number | JJW-600111 |
| Motor | Brush 250W × 2, electromagnetic brake |
| Brake | Electromagnetic brake |
| Battery | DC24V 12AH lithium battery 3 KGS |
| Charger | Input: AC180-240V 50-60Hz; Output: DC24V |
| Charging Time | 6-8 hours |
| Controller | Brush controller |
| Frame Material | Aluminum Alloy |
| Size (Unfold) | 94 * 62 * 96 CM |
| Size (Folded) | 62.5 * 39 * 74 CM |
| Carton Size | 66 * 42 * 81.5 CM |
| Front Wheel | 8 inch PU wheel |
| Rear Wheel | 12 inch wheel |
| Footrest | Aluminum Alloy |
| Seat Width | 45 CM |
| Seat Height | 49 CM |
| Seat Depth | 45 CM |
| Backrest Height | 56 CM |
| Max Load | 150 KG |
| Gross Weight | 32.74 KG |
| Net Weight | 28.2 KG (contains lead-acid battery) |
Product Features
Basic Aluminum Model
The JJW-600111 electric wheelchair is a basic aluminum model with manual folding (non-reclinable), offering 2 optional wheel and connector configurations for customization.
Motor
Brush 250w*2 (with electromagnetic brake)
Battery
DC24V 12AH lithium battery (3 KGS)
Charger
Input AC180-240V 50-60Hz; Output DC24V; Charging time: 6-8 hours
Controller
Brush controller
Frame Material
Aluminum alloy
Dimensions
Unfolded (94*62*96 CM) / Folded (62.5*39*74 CM) / Carton (66*42*81.5 CM)
Wheels
8-inch PU front wheel; 12-inch rear wheel
Footrest
Aluminum alloy
Seat & Backrest
Width 45CM / Height 49CM / Depth 45CM; Backrest height 56CM
Load & Weight
Max load 150KG; Gross weight 32.74kg; Net weight 28.2kg (contains lead-acid battery)
